Module fully automatic testing line

TIM SMT machine

HPAFL

The total length of the equipment is 19.5 meters and the width is 17.5 meters. The entire line equipment can fully realize the automation of heat pipe feeding, inserting and removing rods, laser engraving, automatic powder filling, dust weighing, dust removal, sintering furnace, and graphite disk loading and unloading

Three in one assembly automation

Three in one assembly, testing, and aging automatic assembly line equipment, with a total length of 80 meters, including all assembly and testing processes of OBC. The OEE of the equipment can be stable at around 85%

OBC assembly line

Realize functional MOS bonding - component assembly - glue coating - glue filling&defoaming&curing - screw fastening - PCB assembly - waterway airtightness - whole machine airtightness - drying - safety testing - calibration - burning - aging - EOL, the entire line has complete logic closed-loop anti failure measures, the screw locking process reaches 80% automation rate, and the equipment OEE can be stable at around 85%

3D measuring equipment

Advantages of 3D measurement platform:< Br/>Compatible with all 3D point cloud data types
Multi sensor and multi station fusion calibration
Graphic interaction
Quickly calculate results

BG equipment

Using multi angle visual inspection and big data methods to detect appearance defects on the back cover glass of mobile phones, including dust/foreign objects/residual glue/broken edges and other defects

Mobile CG contour measurement

Fusion calibration of multiple sensors
Multi trip calibration
Submicron level data collection
Visual point cloud and model comparison results

AOI detection category

CF_LD Crack AOI - Edge AOI of CF Load Segment
Cutting Burr Check AOI - Cutting Rear AOI
PFC AOI - AOI before misalignment
PAM-POL bonding accuracy measurement

Adhesive testing category

Apply UV glue to the heat dissipation module, use visual guidance, and cooperate with a piezoelectric valve for high-precision dispensing. Equipped with an automatic adhesive wiping mechanism, weighing module, etc. Utilize visual inspection to assess the dispensing effect in the later stage

PLC testing line

B model reflux path

PLC testing line

The PLC automatic testing line has a total length of 17 meters and a width of 2.35 meters. The equipment can achieve automatic loading and unloading, product transplanting, AOI, HMI calibration, performance testing, and PLC automatic packaging integration

PLC testing line

B model streamline path

PLC testing line

A model streamline path

Charging gun

Charging gun, electronic lock complete set of fully automatic assembly line equipment
